| Model |
HS-120 |
| Display mode |
10" true color touch screen |
| Stripping mode |
Rotating knife stripping (different cable, no need to change the knife) |
| Function |
Automatic cutting and stripping, cable multi-stripping |
| Front stripping |
Cable full stripping MAX 120mm |
| Back stripping |
Cable full stripping MAX 200mm
|
| rWire material |
Cable wire, PVC, Sheathed wire |
| Stripping range |
20 mm² - 120 mm² |
| Cutting length |
1mm-99999.99mm |
| Cutting tolerance |
0.002*L (mm Less than 0.002*cutting length |
| Consult diameter |
10MM～30MM |
| Knife material |
High quality imported high-speed steel |
| Capacity |
More than 12pcs/min (less than 300mm) |
| Drive mode |
32 wheel drive, full servo motor |
| Feeding mode |
Belt feeding, no press no scratch on cable |
