Product category:PV line junction box automation equipment   Back

Product Name:Automatic loose pv terminal crimping machine

Finished shot



Features

●   The equipment adopts new design concept,which can finish cable cutting, stripping,terminal crimping accurately and continually.

●   The machine using synchronous pulley feeding system which assures no hurts on the surface of cable. The products after processed are top-quality, the operation is simple and labor-saving.

●   All adjustment can be made by touchable interface directly,simple and quick.

Technical Parameters

Model HS-61120
Power  AC220V/50/60HZ Single
Function  Cable cutting, one end stripping, both ends stripping, terminal crimping
Processing Capacity  20-24pcs/min(within 1 meter)
Cable Diameter  5mm2以下    Below 5mm2
Cutting Length  100mm-9999mm
Peeling Length  ≤8mm
Pressing Capacity  3T
Detector  Terminal crimping presence
Air Pressure  0.55-1.0Mpa Use a clean, dry gas source
Measurement  1099W x 1050L x 1200H (mm)
Weight  Approximately 190kg
